Sol-Ark 30K-3P-208V-N > 30,000 Watt 208 Volt Three Phase Hybrid Inverter
$14,500.00
Headquartered in Plano, Texas, Sol-Ark is a solar and energy storage technology firm designing and manufacturing multiple inverter lines and load management devices. Founded in 2013 by local U.S. Veterans with immense experience in power electronics, semiconductors, and hardware design, the Sol-Ark team was determined to prepare and protect their own families and businesses from utility power outages by providing reliable and robust solutions.
Description
Headquartered in Plano, Texas, Sol-Ark is a solar and energy storage technology firm designing and manufacturing multiple inverter lines and load management devices. Founded in 2013 by local U.S. Veterans with immense experience in power electronics, semiconductors, and hardware design, the Sol-Ark team was determined to prepare and protect their own families and businesses from utility power outages by providing reliable and robust solutions. The Sol-Ark all-in-one hybrid inverters are best-in-class technology with speed, efficiency, and power as their main advantages, as well as great versatility. Continuing to expand the innovative offering in depth and capability, Sol-Ark added string inverters and micro-inverters enabling a broad diversity of application types. The Sol-Ark mission is to continue making the most reliable, innovative, and robust solar and energy storage solutions to protect families and their businesses. We are “Powering Families Through Life™”. Dedicated to providing world-class customer support and continuing innovation, the Sol-Ark team is carrying out the vision of making solar plus energy storage affordable for all.
Parallel Stacking (1-12), Grid Sell Back: Limited to Household / Fully Grid-Tied, 60kW Peak Power, 124.6kW AC Coupling (277V x 150A x 3 = 125KVA with no PVdc)
-
- Easy Install:
The 30K INVERTER comes with everything you need to install it. Nicely packaged for added efficiency.
- Easy Install:
-
- Fleet Management:
With Sol-Ark’s remote access features and app you are never out of touch to quickly repair or adjust any system without being on site.
- Fleet Management:
-
- AC/DC Coupling:
Supports simultaneous DC and AC coupling. Boosts PV energy without increasing PV array size and reduces storage inverter costs up to 30%
- AC/DC Coupling:
- Warranty and Reliability:
Comes with 10 year warranty and Sol-Ark 7 day a week live support to assist you in all your needs.
Electronics Certified Safety by SGS Labs to NEC & UL Specs – Pending: NEC 690.4B & NEC 705.4/6
Grid Sell Back – Pending: UL1741-2010/2018, IEEE1547a-2003/2014, FCC 15 Class B, UL1741SB, CA Rule 21, HECO Rule 14H
Specifications
Solar – Input Power 78,000W
| Max allowed PV DC Capacity | 39,000W |
| Max PV power delivered to Battery & AC outputs | 30,000 Watts |
| Max DC voltage | 500V@36A |
| MPPT voltage range | 170-500V |
| MPPT Starting Voltage | 150V |
| Number of MPPT | 4 |
| Max Solar Strings Per MPPT | 2 |
| Max DC Current per MPPT (Self Limiting) | 36A |
| Max AC Coupled Input into GEN terminal (Micro/String Inverters) | 60kVA with no PVdc** 30kVA with 39kW PVdc ** Software Limitation: 180A x 120V x 3 |
AC Output Power 60kW On-Grid & Off-Grid
| Nominal AC Output Voltage | 120V / 208V Three Phase |
| Continuous AC Power from PV | 30,000W | 83.4A (208V) |
| Continuous AC Power from Batteries | 30,000W | 83.4A (208V) TBD |
| Surge AC Power 7 seconds | 60,000VA | 167A x 120V x 3 |
| Parallel Stacking | Yes – Up to 12 |
| Frequency | 60/50Hz |
| Continuous AC Power with Grid or Generator | 72,000W 200A L-L (208V) 36,000W 200A L-N (120V) |
| CEC Efficiency | 96.5% (Peak 97.5%) |
| Idle Consumption Typical – No Load | TBD |
| Sell Back Power Modes | Limited to Household/Fully Grid-Tied |
| Design (DC to AC) | Transformerless DC |
| Response Time (Grid-Tied to Off-Grid) | 5ms |
| Power Factor | +/- 0.8 – 1.0 |
Battery (optional) Output Power 60,000W
| Type | Number of Inputs | Li-Ion | 2 Inputs |
| Nominal DC Input | >300V |
| Capacity | 50 — 9,900Ah |
| Voltage Range | 150V ~ 550V |
| Continuous Battery Charging Output | 100A (50A Per Input) |
| Charging Curve | 3-Stage w/ Equalization |
| Grid to Battery Charging Efficiency | 96.0% |
| External Temperature Sensor | Included |
| Current Shunt for Accurate % SOC | Included |
| External Gen Start Based on Voltage or %SOC | Integrated |
| Communication to Lithium Battery* | CanBus & RS485 * ONLY works with Li-Batteries under Closed-Loop Communications |
General
| Dimensions (H x W x D) | 35.2” x 20.8” x 11.6” |
| Weight | 172 lbs |
| Enclosure | IP65 / NEMA 3R |
| Ambient Temperature | -40~60°C, >45°C Derating |
| Installation Style | Wall-Mounted |
| Wi-Fi & LAN Communication | Included |
| Standard Warranty (verified by HALT Testing) | 10 years |
Protections & Certifications
| Electronics Certified Safety by SGS Labs to NEC & UL Specs – NEC 690.4B & NEC 705.4/6 | pending |
| Grid Sell Back — UL1741-2010/2018, IEEE1547a-2003/2014, FCC 15 Class B, UL1741SB, CA Rule 21, HECO Rule 14H | pending |
| PV DC Disconnect Switch — NEC 240.15 | integrated |
| Ground Fault Detection — NEC 690.5 | integrated |
| PV Rapid Shutdown Control — NEC 690.12 | integrated |
| PV Arc Fault Detection — NEC 690.11 | integrated |
| PV Input Lightning Protection | integrated |
| PV String Input Reverse Polarity Protection | integrated |
| AC Output Breakers – 200A | integrated |
| Surge Protection | DC Type II / AC Type III |
